Color Painted 320 Clevis Latch Hook Eye Slip Hook With Latch M16.5 - M90

Brand Name : LKY

Model Number : 320

Certification : CE, ISO

Place of Origin : CHINA

MOQ : 1 ton

Price : Negotiable

Payment Terms : T/T

Supply Ability : 200 tons per month

Delivery Time : 60 days

Packaging Details : Carton + Pallet

Product Name : 320 Eye Slip Hook with Latch

Material : Carbon Steel, alloy

Surface : Color Painted

Size : M16.5 - M90

Packing : Cartong + Pallet

WLL : 0.5 - 135 tons

Contact Now

Color Painted 320 Eye Slip Hook with Latch

320 eye slip hook with latch is designed to use with G80 alloy chain and steel wire rope. It can be applied to shorten or hook long chain. And its structure of eye type make it can be used widely with omega links, connecting links and other lifting components in many circumstance.

Product details:

1. Item: 320 eye slip hook with latch

2. Material: A320-alloy steel/ C320-carbon steel

3. Technology: drop forged

4. Surface: hot dip galvanized, zinc plated or self color

5. WLL: A320:0.21T-27.2T/ C320:3.75T-135T

6. Breaking load: 4 times of working load

7. Usage: lifting, rigging

8. Size: 6mm-32mm

9.Special specifications and marks can be made according to customers requirement

Specification:

Weight	W.L.L.(T)		Φ	E	H	K	L
kg	A320	C320	mm	mm	mm	mm	mm
2.5	0.21	3.75	16.5	19	17	72	97
3.75	0.28	5	19	22	19	82	110
5	0.4	7.5	23	23	21	93.5	125
7.5	0.65	10	28	24	26	103	140.5
10	0.94	15	31	27.5	28	119	162
15	1.95	25	39	33	37	146	201
25	3.77	35	51	40	46.5	186.5	256
37.5	6.8	55	62	51	57	231.5	317
50	9.8	75	73	57	67	261	360
75	16.25	110	89	75	76	318	434
100	27.2	135	90	82	91	360	495.5

Color Painted 320 Clevis Latch Hook Eye Slip Hook With Latch M16.5 - M90

Packing & Delivery

Color Painted 320 Clevis Latch Hook Eye Slip Hook With Latch M16.5 - M90
